| 模数 | Pt | L1 | L2 | 齿数 | B | H | ho | f | a | l | 孔数 | h | d1 | d2 | t | al | ll | d3 | fp2 | fp3 | 订单代码 |
| 5 | 16.66669 | 1000 | 17.4 | 60 | 49 | 39 | 34 | 3 | 62.5 | 125 | 8 | 12 | 14 | 20 | 13 | 37.5 | 925 | 11.7 | 0.005 | 0.020 | 0504R100C10 |
| 6 | 20.00003 | 1000 | 20.9 | 50 | 59 | 49 | 43 | 3 | 62.5 | 125 | 8 | 16 | 18 | 26 | 17 | 37.5 | 925 | 15.7 | 0.005 | 0.020 | 0604R100C10 |
| 8 | 26.66671 | 960 | 28 | 36 | 79 | 79 | 71 | 3 | 60.0 | 120 | 8 | 25 | 22 | 33 | 21 | 120.0 | 720 | 19.7 | 0.006 | 0.022 | 0804R100C10 |
| 10 | 33.33339 | 1000 | 35.1 | 30 | 99 | 99 | 89 | 3 | 62.5 | 125 | 8 | 32 | 33 | 48 | 32 | 125.0 | 750 | 19.7 | 0.006 | 0.022 | 1004R100C10 |
| 12 | 40.00006 | 1000 | 42.6 | 25 | 120 | 120 | 108 | 3 | 40.0 | 125 | 8 | 40 | 39 | 58 | 38 | 102.5 | 750 | 19.7 | 0.007 | 0.023 | 1204R100C10 |
